Tablet Hardness Tester TBH 125

Request a quote
Create PDF

Language:

Small Device - Straightforward Hardness Tests Key Features

Hardness Testing

Measuring range from 10 to 300 Newton

Width Measurement

Test samples with a diameter of up to 28 mm

USB Interfaces

USB-A printer interface for documentation of time, date, results and statistics with specified printers; USB-B interface for firmware updates

100% USP / EP / JP Compliant

Like all ERWEKA products, the TBH 125 is 100% USP / EP / JP compliant

Various Measuring Units

Measuring units in Newton, Strong Cobb and Kilopond

Automatic Calibration Tool AutoCal 2.0

Tablet Hardness Tester TBH 125 Technical Data

Weight6 kg
Dimensions (H x W x D)160 x 310 x 300 mm
Voltage100 - 240 V ± 10% / 50 - 60 Hz / 100 W
InterfacesUSB-A for printer, USB-B for firmware updates
Hardness range10 - 300 N (extended: 10 - 500 N +- 1 N)
Diameter/length/thickness range0.9 - 25.0 mm (± 0.05 mm)
Constant speed0.5 - 3.1 mm/sec.
Constant force10 - 200 N/sec.
CalibrationWeights (statistic calibration)
Optional: AutoCal 2.0 (dynamic calibration)
